Stainless Steel Vertical Fluid Bed Dryer Industrial Powder Granule Drying Machine

Stainless Steel Vertical Fluid Bed Dryer Industrial Powder Granule Drying Machine

Description:

After being filtered through a high-efficiency filter, hot air is sent into the drying chamber from the bottom of the equipment. Passing through a porous distribution plate at the bottom, it evenly blows upwards, causing the powder and granular materials inside to suspend and form a fluidized bed. The hot air makes full and comprehensive contact with the materials, quickly removing internal moisture and achieving uniform drying. The equipment allows for precise control of hot air temperature and volume; low-temperature drying will not scorch heat-sensitive raw materials. Exhaust gas is discharged after dust removal, ensuring a completely sealed process with no dust emissions. After drying, the material can be directly unloaded, allowing for batch-based cyclical operation.

Our stainless steel vertical fluid bed dryer is a batch-type industrial drying machine widely applied in food, chemical, pharma production and fine chemical industries. Constructed with full 304 stainless steel, the machine features transparent observation windows for real-time material monitoring, mobile wheeled frame for easy movement and cleaning, fully complying with GMP workshop standards.

It adopts fluidized low-temperature drying technology, delivering uniform heat distribution to protect heat-sensitive powder and granules from overheating. The sealed structure avoids cross-contamination, with adjustable air volume and temperature to match diverse material drying demands. As a professional factory supplier, we support customized processing on equipment capacity, heating mode and size. This energy-efficient fluidized bed dryer boasts stable running performance, simple operation and low maintenance cost, ideal for mass production of granules, pellets and powdery raw materials. Contact us to get a tailored quotation and technical parameter sheet.

Application:

This vertical fluid bed dryer made of full stainless steel meets GMP standards and is widely used for drying heat-sensitive powder and granules in multiple industries. It is suitable for pharmaceutical materials like herbal granules, pharmaceutical intermediates and capsule fillers; food materials including fruit & vegetable pellets, starch, seasonings, dairy particles and food additives; fine chemical raw materials such as resin pellets, dyestuffs, catalysts, plastic grains and fertilizer powder, as well as feed particles, plant extracts and biological fermentation materials for batch intermittent production in medium and small factories.

Specification:

FAQ:

Q1: What types of pharmaceutical equipment do you manufacture?

We primarily manufacture a series of equipment for crushing, mixing, granulation, drying, coating, and cleaning, and provide complete production line solutions for industries such as health products, food, new energy, and chemicals.

Q2: Do you offer customized solutions?

Absolutely. We can customize equipment dimensions, capacity, control systems, material contact parts, feeding/discharging methods, and automation levels based on your specific production requirements.

Q3: Can your equipment comply with GMP requirements?

Yes. Our equipment is designed and manufactured in accordance with GMP standards. We use high-quality stainless steel materials (SS304 or SS316L), sanitary welding techniques, and easy-to-clean structures to ensure compliance with pharmaceutical production requirements.

Q4: What industries can use your equipment?

· Pharmaceutical manufacturing

· Nutraceutical production

· Food processing

· Chemical industries

· Biotechnology applications

Q5: Do you provide installation and commissioning services?

Yes. We offer installation guidance, commissioning support, operator training, and technical consultation. Remote support and on-site services are available depending on project requirements.

Q6: How do I choose the right machine model?
Our engineering team can recommend the most suitable model based on:
· Product characteristics
· Batch size
· Production capacity
· Facility layout
· Automation requirements
· Regulatory standards
Simply contact us with your requirements for a free consultation.

Q7: What is the lead time for production?

The specific delivery time depends on the machine type and configuration. The exact delivery cycle will be confirmed during the quotation process.

Q8: How do you ensure product quality?

Each machine undergoes the following processes:

Raw material inspection

Precision machining

Functional testing

Quality inspection and Factory Acceptance Testing (FAT)

Only qualified equipment is delivered to the customer.
