High-efficiency Spherical Polishing Shot Machine For Producing Perfectly Round Pellets
Description:
This machine uses a rotating centrifugal disc, a blower, and a pneumatic spray gun to form beautiful spherical pellets from wet granules. The wet granules produced in the previous process are put into the rotating centrifugal disc, the blower is started, and then the rotating centrifugal disc is started. The wet granules are subjected to the buoyancy of the annular gap air, the rotational centrifugal force, and their own gravity, causing them to move in a circumferential rope-like motion, thus forming spherical pellets with extremely high sphericity.
The spherical shot blasting machine is a high-efficiency granulation equipment specifically designed for wet particle shaping. It is primarily used to rapidly process strip-shaped or irregular wet particles into smooth, highly rounded spherical particles. The equipment employs the centrifugal rotary shot blasting principle, enabling the material to quickly complete spherical formation under the friction between the high-speed rotating disc and the cylinder wall. It boasts advantages such as stable operation, convenient operation, and a high spherical formation rate.
Application:
It is suitable for rounding and polishing granules after wet granulation. It is widely used in the preparation of capsule filling granules, sustained-release granules, micro-pellets, instant granules, functional food granules, catalyst granules, spheroidization of chemical raw materials, and research and experimental testing of new granulation processes.
Specification:
|
Specification
|
φ230
|
φ400
|
φ500
|
φ700
|
φ1000
|
φ1300
|
|
Power(Kw)
|
0.75
|
2.2
|
3
|
3.7
|
5.5
|
7.5
|
|
Capacity(Kg/h)
|
2.5-4
|
5-8
|
8-16
|
40-80
|
70-150
|
100-300
|
Feature Advantage:
1. Quickly shapes irregular particles into highly spherical pellets.
2. Improves product flowability and filling performance.
3. Convenient parameter adjustment and stable, reliable operation.
4. Stable operation and low maintenance costs.
FAQ:
Q1: What types of pharmaceutical equipment do you manufacture?
We primarily manufacture a series of equipment for crushing, mixing, granulation, drying, coating, and cleaning, and provide complete production line solutions for industries such as health products, food, new energy, and chemicals.
Q2: Do you offer customized solutions?
Absolutely. We can customize equipment dimensions, capacity, control systems, material contact parts, feeding/discharging methods, and automation levels based on your specific production requirements.
Q3: Can your equipment comply with GMP requirements?
Yes. Our equipment is designed and manufactured in accordance with GMP standards. We use high-quality stainless steel materials (SS304 or SS316L), sanitary welding techniques, and easy-to-clean structures to ensure compliance with pharmaceutical production requirements.
Q4: What industries can use your equipment?
· Pharmaceutical manufacturing
· Nutraceutical production
· Food processing
· Chemical industries
· Biotechnology applications
Q5: Do you provide installation and commissioning services?
Yes. We offer installation guidance, commissioning support, operator training, and technical consultation. Remote support and on-site services are available depending on project requirements.
Q6: How do I choose the right machine model?
Our engineering team can recommend the most suitable model based on:
· Product characteristics
· Batch size
· Production capacity
· Facility layout
· Automation requirements
· Regulatory standards
Simply contact us with your requirements for a free consultation.
Q7: What is the lead time for production?
The specific delivery time depends on the machine type and configuration. The exact delivery cycle will be confirmed during the quotation process.
Q8: How do you ensure product quality?
Each machine undergoes the following processes:
Raw material inspection
Precision machining
Functional testing
Quality inspection and Factory Acceptance Testing (FAT)
Only qualified equipment is delivered to the customer.
